Introduction

Matter Over WiFi Smart Wall Switch

User Manual

This is a smart wall switch that supports 2.4GHz Wi-Fi, uses live-neutral wiring, and is compatible with the Matter ecosystem, allowing seamless integration with smart devices from other brands to build your home automation.

Matter Compatibility
Detach Relay Mode
Smart Schedule
Smart Scene

① Switch Button

  • Single press: Turn on/off the smart device

② Device Button

  • Single press: Turn on/off the smart device
  • Press and hold for 5 seconds: Device enters the pairing mode. (Pairing time 10 minutes)

③ LED indicator (Blue)

eWeLink Mode

  • Flashes two short and one long: Device is in pairing mode.
  • Keeps on: Device is online.
  • Quick flash once: Device offline.
  • Quick flash twice: Connected to the router, but not connected to the cloud.

Matter Mode

  • Flashes two short and one long: Device is in pairing mode.
  • Keeps on: Device is online.
  • Quick flash once: Device offline.
Platform Certification
Specification

Product name

Orb-MW1

Product series

Fusion series

Product type

Matter over WiFi smart wall switch

Model

MINIR4M-E

MCU

ESP32-C3FN4

Rating

100-240V~ 50/60Hz 10A Max Resistive load μ

Wi-Fi

IEEE 802.11b/g/n 2.4GHz

Net weight

84g

Product dimension

86x86x34mm

Color

White

Casing material

PC

Diameter of wiring (recommend)

16AWG to 14AWG SOL/STR copper conductor only

Applicable place

Indoor

Working temperature

10T40 (-10℃~40℃)

Working humidity

5-95%RH, non-condensing

Certification

CE/RoHS

Installation

1. Power off

WARNING

Please install and maintain the device by a professional electrician. To avoid electric shock hazards, do not operate any connection or contact the terminal connector while the device is powered on!

2. Wiring instruction

To ensure the safety of your electrical installation, it’s essential that either a Miniature Circuit Breaker (MCB) or a Residual Current operated Circuit-breaker with Integral Overcurrent protection (RCBO) with an electrical rating of 10A has been installed before the MINIR4M-E.

Make sure all wires are connected correctly.

Instructions for wiring symbols

Terminals

Wires

N

Neutral Line

N

Neutral Line

L In

Live Line

L In

Live Line (100-240V~)

L Out

Live Output Terminal (100-240V~)

3. Power on

When the device is used for the first time, it will enter pairing mode by default after being powered on. At this time, the LED indicator will flash in a pattern of “two short and one long”.

The device will exit the Pairing Mode if not paired within 10mins. If you want to enter this mode, please long-press the button for about 5s until the LED indicator changes in a cycle of two short and one long flash and release.

Matter Ecosystem User Guide

Open a Matter-compatible App to scan the Matter QR code on the Quick Guide or the device itself to add the device.

Add to Apple

via Matter

Add to Google

via Matter

Add to Alexa

via Matter

Add to SmartThings

via Matter

Add a Device

eWeLink Ecosystem User Guide

① Download the eWeLink App

Please download the “eWeLink” App from Google Play Store or Apple App Store.

② Scan QR code to add the device

Enter “Scan”.

Scan the QR code on the quick guide or the device

Select “Add Device”.

(If the device exits pairing mode) Long press the button for 5 seconds

Check LED indicator flashing status (Two short and one long)

Search for the device and start connecting

Select the “Wi-Fi” network and enter the password

Device “Added completely”

Installation

Factory Reset

Reset the device to factory settings by “Delete device” in the eWeLink App.
